Master Cylinders & Rebuild Kits

AP MASTER CYLINDERS

  • The ultra light weight (.7 lbs.) aluminum alloy cylinders
  • Suitable for dual purpose brake and clutch applications.
  • The full stroke is 1" with a 3/8- 24 outlet and a 7/16-20 inlet.
  •   The 2 mounting flange holes are on 2.5" centers
  • Typical for both AP and Girling units.
  • The push rod length is 4.53" with a 5/16-24 thread.

master cylinder CP2623.jpg (6617 bytes)

CP2623 Remote Alloy Master Cylinder
Part No. Size Price
JH-2102-CP2623-625

5/8 Bore

$229.95
JH-2102-CP2623-700

.70 Bore

229.95
JH-2102-CP2623-750

3/4 Bore

229.95
H-2102-CP2623-780

7/8 Bore

229.95
H-2102-CP2623-812

13/16 Bore

229.95


AP REMOTE RESERVOIRS
Part No. Dia. Height Price
JH-2500-CP2293-68 2.60" 4.53"

$49.95
JH-2500-CP2293-143 2.60" 4.53"

49.95
JH-2500-CP4709-13 1.75" 3.78"

49.95
JH-2500-CP4709-15 1.75" 7.32"

49.95

Brake AP reservoir small FR2.gif (4691 bytes)

CP4709-13
CP4709-15

Brake Reservoir AP large central FR4.gif (6390 bytes)

CP2293-68

Brake AP reservoir offset FR3.gif (7382 bytes)

CP2293-143
